Item specifics
  • Display Type: Touch Screen
  • Screen Size: 8-inch
  • Processor Series: Intel Atom
  • Port: LAN
  • Model Number: Z2
  • Type: All-In-One
  • Memory Capacity: 2GB
  • Processor Brand: Intel
  • Brand Name: Partaker
  • Graphics Card Type: Integrated Card
  • Products Status: Stock
  • Processor Model Number: Intel Atom D2550 Dual Core 1.86Ghz
  • Operating System: Android 4.4.4
  • Hard Drive Capacity: 64G SSD
  • Screen Type: Made-In-China 4 Wire Resistive Touch Screen
  • CPU: Intel Atom D2550 Dual Core 1.86Ghz
  • OS: Windows Or Linux
  • RAM/SSD: Maximum 4G RAM,1* Msata SSD
  • USB Port: 4*USB2.0
  • Dimension: 218*176*50(mm)
  • BIOS: AMI 32Mbit
  • LAN: 2* Realtek 8111E
  • Hard Drive Capacity: 60GB
Product Description



 all in one pc



all in one computer

Editor Notes



Model Number:

Partaker Elite Z2

Screen Size:

8 Inch

Opening Hole Size:

207*165mm (Length*Width)

Screen Type:

Made-In-China 4 Wire Resistive Touch Screen

CPU:

Intel Atom D2550 Dual Core 1.86Ghz

OS:

Windows Or Linux

RAM/SSD:

Maximum 4G RAM,1* Msata SSD

I/O:

4*USB2.0/3*COM

I/O:

1*VGA/1*HDMI/2*RJ45

I/O:

1*DC

Physical Dimension:

218*176*50(mm)

Gross Weight:

2KGS



2GB Ram 64GB SSD Inculded.

Attributes

Usage Environment

Operating Temperature:

-10℃~60℃ Surface Air Flow

Operating Humidity:

10% ~ 95% @ 40 ℃ without condensation

Storage Temperature:

-20 ℃ ~ 70 ℃



Installation Method:

1. Embedded (Recommended)

2. Wall-mounted

3. Desktop

4. Cantilevered

5. Other Installation Methods



Motherboard:

BIOS:AMI 32Mbit,Support Diskless Start, Wake-Up on Lan, Call Boot (Power On Boot), Watchdog And Other Functions

Display Mode:Single Display; VGA+LVDS,HDMI+LVDS Synchronous / Asynchronous Dual Display

Motherboard Fan:



I/O Interface:

Network: 2* Realtek 8111E 10/100/1000M Adaptive Network Card Chip

Audio: Realtek®ALC662 HD Audio Decoding Core



Quality Inspection

Each Partaker Industrial All In One Computer will conduct a number of strict testing, including performance testing, temperature testing, vibration, pressure, LED screen aging, interface testing, electronic load, touch screen detection

Before shipment, the appearance of Partaker Industrial All In One Computer, performance, interface, 24-hour aging test to ensure that each is superior quality.



Company Profile

Focus on the industrial sector for 8 years, your most reliable suppliers

INCTEL Technology focus on All in One touch-screen, infrared touch All in One Computer, resistance touch All in One PC, advertising, touch products such as the development and production. For industrial control, commercial display, advertising, business meetings, games, entertainment, medical equipment and other fields, introduced a professional application solutions.



Package Information:

Package Size

25.5CM(L)*21.5CM(W)*15CM(H)

Physical Weight

1.3KG / 2.0KG(Net/Gross)

Power Supply

Input: 180-240V~1.0A 50-60Hz Output: 12VDC  4A MAX

Power Cord

Power Cord*1

Buckle

Embedded Installation Buckle* 1 Set








Gallery

Z2 (1)Z2 (2)Z2 (3)Z2 (4)Z2 (5)Z2 (6)Z2 (7)Z2 (8)





 Z2 (9)













Packaging Details
  • Unit Type: piece
  • Package Weight: 2.5kg (5.51lb.)
  • Package Size: 1cm x 1cm x 1cm (0.39in x 0.39in x 0.39in)
