Item specifics
  • Processor Model Number: D2550
  • Dispaly Ratio: 4:3
  • Hard Drive Capacity: 120GB
  • Processor Series: Intel Atom
  • Display Type: LCD
  • Type: All-In-One
  • Memory Capacity: 4GB
  • Model Number: IN-2D4M
  • Brand Name: Partaker
  • Port: HDMI+VGA
  • Graphics Card Type: Integrated Card
  • HDD Rotation Speed: 7200 rpm
  • Drive Type: No CD ROM
  • Products Status: Stock
  • Processor Main Frequency: 1.86
  • Screen Size: 12.1inch
  • Power: 20W
  • is_customized: Yes
  • Memory Capacity: Shared Memory
  • RAM Type: DDR
  • HDD Interface: SATA
  • Graphics Type: Integrated Card
  • Sound Card Type: 6.1
  • Operating System: Windows 7
  • Optical Drive Type: CD-ROM
Product Description

Intel Atom D2550 Windows7 All in One Computer with 12 inch Touch Screen 4G RAM 128G SSD

Editor Notes.jpg

Multifunction self-service computer provides 10 to 15 inch multi-touch screen,

a variety of services to meet the required applications, such as retail shelves billboard

exhibition interactive information systems, campus curriculum inquiry system and

even healthcare institutions versatile bedside stand. Easy to clean the whole plane of

the touch panel IP65 protection with slim design, can show the advantages of the various

service applications; programmable touch shortcut keys and a wealth of microphones,

radio frequency identification (RFID), the smart card chip reader , bar code scanners,

magnetic stripe card reader (MSR) and other options,

suitable for use in a variety of contexts.

Model  IN-2D4M
CPU Intel Atom D2550 Dual Core
GPU Integrated Intel GMA 3600 graphics core  Four Thread 1.86Ghz 1MB
RAM Support NB Memory SO-DIMM DDR3 (Maximum to 4G RAM)
Storage Support 1*Mini PCIE Msata SSD+1* 2.5" HDD/SSD (SSD Max.512G, HDD Max. 1TB)
Wi-Fi Wireless-(150Mbps or 300Mbps optional)

AIO+Power Supply+Power Cord (USA, European, UK Types for optional)+Stand

Rear I/O:






Audio input and output


With Fan

Upgrade Service:

1. WiFi Optional, if need wifi,(150Mbps) builtin wireless add extra $8, (300Mbps) add $10. Choose one from 150M and 300M.

2. Wall Mount add $10

3. USB Bluray DVD add $48, Normal DVD add $28

4. More configuration about lower or higher RAM, HDD, SSD Options, please refer to our big directory or contact our pre-sales for guide.

Ref. Photo as belows,

Wall mount Photo

Upgrade link for the upgrade service:

(Upgrade rules, such as upgrade 150M wifi, buy 8pcs for $8, 300M wifi, buy 10pcs for $10, Upgrade value, 1pc=$1)

4G RAM, 128G SSD

If customer buy the configuration with RAM, SSD, HDD, We can install system as belows,

XP/windows 7/Ubuntu Linux optional

(if not leave message, we will ship at Random.)

Charged WIN.8/8.1 add extra $5, Server 2003 add extra $5

Above is Cracked English Version.

Original Windows, please buy it locally!

For bulk orders/Bid Goverment orders, we can supply original embeded windows. (MOQ:10 Sets,inquiry our pre-sales)


Full Metal Jacket , 2mm ultra-thin panel design , suitable for flush mounting , the original 12-inch LED LCD panel with a resolution of 1024 * 768, optional WIFI module, with a separate package .


309.1mm * 247.5mm

Hole Size:

295mm * 234mm


12.1 -inch LED screen resolution of 1024 * 768 Industrial

Touch screen:

Industrial 4 -wire resistive screen


ATOM D2550 Dual Core 1.86G


1000M ( optional wireless card plus 50 yuan )

Built-in speakers :

Mono 2W

The lower side of the interface :

DC_IN * 1, LAN * 2, USB * 2, VGA * 1, HDMI * 1, AUDIO * 2, RS232 * 2

Back of the interface :

USB * 2

Machine weight :


Package Contents:All-in-one touchscreen pc, 12V 4A power supply,power cord, Flush mounting clips*4

Product Features :

12V DC input , Power consumption 20W, support calls boot, Wake on LAN

Machines preloaded WINXP Or windows 7, good stability , bootable work long hours

Note : This machine WINXP system graphics driver does not support 3D hardware acceleration, 3D applications can not run if there is a need , you must use WIN7 system


About Power Cord:

We will ship the type of power cord, based on your area.

Power Cord.jpg


 12.1 inch all in one pc (1).jpg12.1 inch all in one pc (2).jpg12.1 inch all in one pc (3).jpg12.1 inch all in one pc (5).jpg12.1 inch all in one pc (4).jpg


Packaging Details
  • Unit Type: piece
  • Package Weight: 6.0kg (13.23lb.)
  • Package Size: 36cm x 33cm x 13cm (14.17in x 12.99in x 5.12in)
