Item specifics
  • Display Type: Touch Screen
  • Processor Series: Intel Celeron
  • Model Number: Z6
  • Port: LAN
  • Type: All-In-One
  • RAM Type: DDR3
  • Memory Capacity: 2GB
  • Processor Brand: Intel
  • Brand Name: Partaker
  • Graphics Card Type: Integrated Card
  • Processor Model Number: Bay Trail Celeron J1900 Quad Core 2.0Ghz to 2.4Ghz
  • Products Status: Stock
  • Processor Main Frequency: 2.0
  • Screen Size: 10.1 inch
  • Hard Drive Capacity: 32G SSD
  • HDD Interface: SATA
  • Operating System: Windows 7
  • Graphics Type: Integrated graphics
Product Description

all in one pc



all in one computer

Editor Notes

Model Number:

Partaker Elite Z6

Screen Size:

10.1 Inch

Opening Hole Size:

227*183mm (Length*Width)

Screen Type:

Made-In-China 4 Wire Resistive Touch Screen

CPU:

Bay Trail Celeron J1900 Quad Core 2.0Ghz to 2.4Ghz

OS:

Windows Or Linux

RAM/SSD:

Maximum 8G RAM, 1* MSATA SSD

I/O:

2*USB2.0/2*USB3.0/2*COM

I/O:

1*VGA/1*HDMI/1*RJ45

I/O:

1*DC/MIC-IN&LINE-OUT

Physical Dimension:

270*192*47(mm)

Gross Weight:

4KGS

Attributes

Opening Hole Size Drawing:


Features:

10.1 Inch Backlit LED Screen, 1024*600 Resolution

Stable performance, support 7 * 24 hours of uninterrupted operation

Available in black and white

Optional WiFi module, support for 802.11b / g / n

Standard VESA screw hole, can choose the installation method flexibly

Support Win7, Win8, Win10, Linux etc….



Panel Structure:

Panel Size

10.1 Inch LED Screen

Resolution

1024*600

Display Brightness

250cd/m(2)

Contrast

800 : 1

Response Time

5ms

Touch Type

Resistive touch screen



Package Information:

Package Size

32.4CM(L)*25.5CM(W)*12.7CM(H)

Physical Weight

2.5KG / 3KG(Net/Gross)

Power Supply

Input: 180-240V~1.0A 50-60Hz Output: 12VDC  4A MAX

Power Cord

Power Cord*1

Touch Pen

Resistance touch pen*1

Buckle

Embedded Installation Buckle* 1 Set



Usage Environment

Operating Temperature:

-10~60 Surface Air Flow

Operating Humidity:

10% ~ 95% @ 40  without condensation

Storage Temperature:

-20  ~ 70



Installation Method:

1. Embedded (Recommended)

2. Wall-mounted

3. Desktop

4. Cantilevered

5. Other Installation Methods



Motherboard:

BIOS:AMI 32Mbit,Support Diskless Start, Wake-Up on Lan, Call Boot (Power On Boot), Watchdog And Other Functions

Display Mode:Single Display; VGA+LVDS,HDMI+LVDS Synchronous / Asynchronous Dual Display

Motherboard:Fanless Design



I/O Interface:

Network: 1* Realtek 10/100/1000M Adaptive Network Card Chip

Audio: Realtek®ALC662 HD Audio Decoding Core

Gallery

DSC_3408






DSC_3412DSC_3417DSC_3567DSC_3575DSC_3583
