Item specifics
  • Resolution: 1920 x 1440
  • Products Status: Stock
  • Brand Name: ckl
  • Computer Connections: 8 Ports
  • Package: Yes
  • Monitor Connections: 8 Ports
  • Model Number: CKL-8A8
  • Interface Type: VGA
Product Description

Key Features:

1.8 ways VGA signal + 8 AUDIO signal output.

2. LED lamp for the detection of each input / output device connection status.

3. LED digital tube display each path corresponds to the input port number.

4. Various scenes of storage and call, single channel or full channel browsing.

5. Power off protection.

6. High bandwidth matrix switching chip, image clarity and stability.

7.200ns Using high-speed switching circuit, the switching time 200ns.

8. Multiple control modes: the front panel buttons, infrared remote control.

9. Matrix design, arbitrary cross input output.

Technical Data:

Input signal

VGASVGAXGAWXGAStereo audio

Input connector

15 pin HD socketDC3.5

Input level

0.7 Vp-p

Video bandwidth

450MHz (-3 dB) full load

Output signal

VGASVGA, XGAWXGAStereo audio

Output connector

15 pin HD socketDC3.5

Output level

0.7 Vp-p

Impedance

75 ohms

Control method

Panel key    Infrared remote controller

Power supply voltage

AC220V/50HZ

Operating temperature range

0 ~ 50 Degree Celcius

Special reminder: If VGA connecting line for Connecting the input / output device is not provided by the company, please ask the VGA wire distributor before buying if the tenth feet of both ends of the connecting line can connect to other earth wire. If not, it will cause the device to the input / output LED detection indicator light is not bright.

Packaging Details
  • Unit Type: piece
  • Package Weight: 3.5kg (7.72lb.)
  • Package Size: 52cm x 12cm x 24cm (20.47in x 4.72in x 9.45in)
